S&A recirculating chiller CW-6100AT for Raycus 500W Laser

S&A recirculating chiller CW-6100AT for Raycus 500W Laser

S&A CW-6100AT dual temperature and dual pump series is high-precision compression refrigeration water chiller,with intelligent temperature control,completed configuration,perfect protection and alarm system. It is fit for cooling Raycus 500W laser.

S&A CW-6100AT is able to cool the fiber laser and optic lense at the same time, multiple use for saving cost, space and manual move, quiteconvenient for the user.

S&A water chiller CW-6100AT features

1. 4200W cooling capacity; optional environmental refrigerant;

2. ±0.5℃ precisely temperature control;

3. The intelligent temperature controller has 2 control modes, applicable to different applied occasions; with various setting and display functions;

4. Dual temperature and dual pump to satisfy different needs of fiber laser device and the lens;

5. With Ion adsorption filtrating and test functions conform to fiber laser device operating requirements;

6. Multiple alarm functions: compressor time-delay protection, compressor overcurrent protection, water flow alarm and over high / low temperature alarm;

7. Multiple power specifications; CE approval; RoHSREACH approval;

8. Long working life and easy operation;

9. Optional heater and water filter.

CW-6100AT parameter:

Voltage: 220V; Frequency: 50/60Hz; Refrigerant: R-22 / R-410a

Pump power: 0.1KW+0.55KW; Tank capacity: 4L+12L

Max. lift: 25M+36M; Max. flow: 16L/min+70L/min

N.W: 90Kgs; G.W: 100Kgs;

Dimension : 78 X 47 X 89 cm (L X W X H); Packing dimension: 87 X 60 X 109 cm(L X W X H)
