SAE Type 1 Charging Cable

AG ELECTRICAL is one of the top electric vehicle charging equipment manufacturers, our GBT EV Charging products are sold to many countries all over the world. Our GBT EV Charging Components can meet the needs of different customers in different areas to the maximum extent.

Mechanical Properties

108. Mechanical life: no-load plug>10000times
108. Impact of external force: be able to afford 1m drop and 2tons vehicle run over pressure
108. Insertion and extraction force: <100N</span>

Electrical Performance

108. Rated current: 16A/20A/32A
108. Rated voltage: 120V/250V
108. Insulation resistance: >1000MΩ(DC500V)
108. Pins temperature rise: <50K</span>
108. Withstand voltage: 2500V
108. Contact impedance: 0.5mΩMax

Raw Material

108. Shell material: thermoplastics, flame retardant grade UL94-0
108. Plug pin: copper alloy, silver-plate

Environmental Performance

Temperature: -30℃~+50℃

SAE Type 1 Charging Cable Features

108. Conform to the provisions and requirements of SAE J1772 Standard-2012, it can charge all EV manufactured in the USA, correctly and effectively with high compatibility.
108. Using a riveting pressure process with none screw with beautiful appearance. Hand-held design conforms to ergonomic principle, plug conveniently. The head of pins using insulation design to prevent direct contact with the hand. The customer is able to install the charger indoors or outdoor, according to actual demand. Firmly locking the charger on the installation backplane can prevent theft.
108. XLPO for J1772 cable insulation prolonging the aging resistance life-span. TPU sheath improves the bending life and wears resistance of the J1772 replacement connector. The best material in the market at present conforms to the latest European Union standards.
108. Special internal waterproof protection performance, protection grade achieved IP55 (working condition). The shell can effectively insulate the water from the body and enhance the safety level even in bad weather or special circumstances.
108. Adopted double color coating technology, custom color accepted (the regular color orange, blue, green, gray, white)
108. Keep the laser logo space for customers. Provide OEM/ODM service to help customers expand the market easier.

Application of SAE Type 1 Charging Cable Features

Apply to Vehicle

Tesla model3, Tesla Model S, Tesla Model X, BAIC EU-Series, BYD Yuan/S2 EV, BYD e5, Chevrolet Volt, Mia, Mia Electric Van, Mitsubishi OUTLANDER PHEV, Nissan NV200 SE Van, Nissan leaf, SAIC Baojun E-Series, SAIC Roewe Ei5 EV, BMW 530e/Le, Renault Zoe, Hyundai Kona EV, BMW i3, BYD Tang PHEV, Chery eQ EV, Toyota Prius PHEV, Volkswagen e-Golf, Geely Emgrand EV, Great Wall Ora R1 EV

Application in area

Commercial EV Charging/Workplace EV Charging, Hotels EV Charging, Home/Residential EV Charging, Public EV charging

SAE Type 1 Charging Cable Features Parameter

AG ELECTRICAL EV Charging J1772 connector for sale acquires all safety and production certificates in electrical filed, ISO9001, ISO 14001, OHSAS 18001, SAE J1772-2012
