Security System Battery
Part number of security system battery:
12.8V 200Ah LFP Battery
Features of security system battery replacement:
• All day, 24 hours discharging
• Use in Security Alarm System, communication equipment
• BMS from imported brand,stable working
• Long running life, High stability, Low maintenance costs
• Heat insulation design to longer cells running life
• Stable floating charge
• Portection with Overcharge / Overdischarge / Overcurrent / Short circuit / temperature protection to ensure safety while using
• Wide operating temperature range
• Low-power consumption,Long standby time
• IP45 Rating, Anti-vibration,Fall protection
• RoHS eco-friendly design
• Cell approved by UL1642, IEC62133, UN38.3 certification
• PCM & cell double protection to ensure the battery safety
Security System Battery Replacement
- Specification of security system battery:
Item |
Parameter |
Model |
12.8V 200Ah LFP Battery |
Model Capacity |
200Ah |
Minimum Capacity (0.5C,A) |
195Ah |
Rated Voltage |
12.8V |
Max Charge Voltage |
14.6V |
Cut-Off Voltage |
8.4V |
Standard Charge And Discharge Current |
20A |
|
|
Item |
Parameter |
Maximum Continuous Charge Current |
30A |
Max Continuous Discharge Current |
30A |
Weight (Approx. Includes Case) |
~23Kg |
Impedance (Max, At 1000Hz.) |
≤70mΩ |
The Factory Voltage |
≧12.8V |
Charge Method (CC) |
20A 14.6VCut Off |
Charge Method (CV) |
14.6V 2ACut Off |
2.Bock diagram of security system battery:
The product adopts a pure hardware protection scheme, same port input and output, supports single-cell voltage monitoring function, temperature monitoring function, current monitoring function, and equalization function to ensure stable performance, safety and long-term use of the product.
Security System Battery
3.Outline Drawing of security system battery:
The SPCC shell solution is full of industrial sense. The dual-handle design is convenient for installation and transportation. The internal shock absorption solution allows the product to be placed on multiple sides and is suitable for more complex environments. The actual size: 375mm*252mm*160mm.
Security System Battery
4.Security System Battery Replacement:
Security system replacement battery: The security battery produced by PLB has an ultra-wide operating temperature range, low power consumption and long battery life, meets IP45 requirements, complete lithium battery protection functions, low power consumption, long standby, and guarantees safe use of the battery and long life Highly stable, it is the best solution to replace lead-acid batteries.
As one of the professional chinese lithium battery companies, we provide china lithium battery, Lithium iron phosphate battery and etc. If you want to know lithium battery price or more, please contact us.
