SFP BIDI CWDM 1.25G 40KM Transceiver

Description

SFP BIDI CWDM 1.25G 40KM Transceiver Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The transceiver consists of five sections: the LD driver, the limiting amplifier, the digital diagnostic monitor, the DFB laser and the PIN .The module data link up to 40KM in 9/125um single mode fiber.The optical output can be disabled by a TTL logic high-level input of Tx Disable, and the system also can disable the module via I2C. Tx Fault is provided to indicate that degradation of the la+ser. Loss of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver or the link status with partner. The system can also get the LOS (or Link)/Disable/Fault information via I2C register access.

Features

1．Up to 1.25Gb/s data links

2．DFB laser transmitter

3．PIN photo-detector

4．Up to 40KM on 9/125µm SMF

5．Hot-pluggable SFP footprint

6．BIDI LC/UPC type pluggable optical interface

7．Low power dissipation

8．Metal enclosure, for lower EMI

9．RoHS compliant and lead-free

10．Single +3.3V power supply

11．Support Digital Diagnostic Monitoring interface

12．Compliant with SFF-8472

13．Case operating temperature

14．Commercial: 0°C to +70°C

15．Commercial: 0°C to +70°C

Applications

1．Switch to Switch Interface

2．Gigabit Ethernet

3．Switched Backplane Applications

4．Router/Server Interface

5．Other Optical Links
