Silicone Rubber For Tyre Molding
Quantité : 200kg Prix : 10-14usd/kg
Description
HY- E series addition molding silicone is generally named two-components silicone
rubber, Part A and part B. It features an exceptional fluidity and good operability.
The mixing ratio is 1: 1 (10: 1),mainly be suitable for making molds application.
Typical Applications
HY- E series addition molding silicone could be mainly used for making concrete
stones, wax molds, PU molds, resin molds, gypsum casting, candle molding and
chocolate , candy and any other FDA food product mold making,prototyping etc.
HY-E620 Silicone Rubber is has been used for years to make tire pattern molds .
Characteristics
* low shrinkage (less than 0.1% )
*high tensile and tear strength with high copy times
*easy for operation (mixing ratio at 1: 1 /10: 1)
*very good flow and easy for pouring operation
*Fast and non-shrink cure at room temperature which can be accelerated considerably by the applicati on of heat
Technical Parameters
|
Product |
E-620 |
|
Appearance |
Translucent |
|
Hardness(shore A) |
20±2 |
|
Mix ratio(A: B) |
1: 1/10: 1 |
|
Viscocity Part A(mPa.s) |
23000±2000 |
|
Viscocity Part B(mPa.s) |
3500±500 |
|
Tensile strength (kgf/cm2) |
45±5 |
|
Tear-strength (kN/m) |
20±2 |
|
Elongation(%) |
500±50 |
|
Pot life/working time (mins) |
30-40 |
|
Curing time/setting time (hrs) |
3-4hrs(25℃) 110-20mins(60℃) |
|
Shrinkage rate (%) |
0.1 |
(Please note: the above data for this product in 25℃ temperature, 55percent humidity conditions, for reference. T he accurate data is measured by customers when using.)
Operation instruction of HY-E Series molding silicone:
1. Pls clear the model and tool totally before operation to prevent cure inhibition.
2.Weigh the two part correctly by electronic weight in two separate container .
3. Mixing the two part in 1: 1/10: 1 and stir part A and part B evenly in 2-3 minutes .
4.And get the mixture for vacuum-pumping for de-air the bubble in around 2-3
minutes . (If there is no vacuum machine, pls pour the mixture carefully and slowly
down the side of the mold frame so that less bubbles caused)
5. Enclose the product (the original model) with four plastic plates or wooden plates.
6. Clean your products and brush a layer of release agent(detergent or soap water) on
your product.
7. Pour the vacuumed mixture into the model frame from the side of the mold frame .
