Solar LED Reflective Road Studs Model No. ZOJE-RS105

Led road stud is the flashing solar cell powered and maintenance-free lighting device used in road construction to delineate and /or illuminate the lanes to road users during the day and night.
2) The green reflective studs are charged up during the day by sunlight through the solar panels and flash at night. Embedded in the road surface, led road stud is an electronic improvement on the traditional cats' eyes in that led road stud may give drivers more than thirty-second reaction window compared with about 3 seconds for conventional reflective devices.
3) The led road stud is also more visible in rainy and foggy conditions which are problematic for the old plastic reflective road markers.
4) The green reflective studs reduce the necessity of headlight main beams and the accompanying hazard of dazzling oncoming drivers.
Why ZOJE
Solar powered high intensity LED for superior performance in luminosity.
High-quality Ni-Mh battery adapting high temperature.
Improved design, reflective installed inside, better water proof performance: IP68
Aluminum shell with strong compressive resistance.
Easy to install with virtually no maintenance.
Red blue white yellow-green color.
The double side led road stud or single face green reflective studs can be designed.
Wher e would you find green reflective studs? Just come and contact us!
Specification of Green Reflective Studs
Model ZOJE-RS105
Material Aluminum+PC
Power supply Monocrystalline solar panel
2.5V/150mA for NI-MH
5V/60mA for lithum battery
3V/120mA for super capacitor
Battery NI-MH 1.2V/ 600mAh(high temperature resistance)
Lithum battery 3.2V/500mA
Super capacitor2.3V/120mA (made in Korea)
Lens PMMA(ASTM D4280 & EN 1463-1 standard)
LED Ultra bright, diameter 5mm( 6pcs)
LED color Red,yellow,green,blue,white
Working model Blinking or constant(charged at daytime, working automatically at night)
Working hours (1).Blinking: 140hours for NI-MH battery; 130hours for lithum battery;
30hours for super capacitor after fully charged
(2).Constant: 40hours for NI-MH battery; 35hours for lithum battery;
15hours for super capacitor after fully charged
Visual distance >800m
Water proof IP68
Resistance 20T
Lifespan 2years for NI-MH battery;
5years for Lithum battery;
10years for 120F super capacitor
Size 123mm*133mm*22+55mm
Packing 1pc/box;45pcs/ctn
Carton size 66.5*44*28cm
Weight 30kgs/ctn
Certificate CE & ROHS
