Telescopic Man lift 20-22M
We are professional telescopic manlift20-22M supplier and factory in China. We can produce the product according to your requirements.
Telescopic platform lift 20-22M Measurements & Specifications
MODEL |
GTBZ20 |
GTBZ22 |
|||
MEASUREMENTS |
Metric |
US |
Metric |
US |
|
Working height maximum * |
22.4m |
73ft |
23.9m |
78ft |
|
Platform height maximum |
20.7m |
68ft |
22.2m |
73ft |
|
Horizontal reach maximum ** |
19.1m |
63ft |
20.2m |
66ft |
|
Below ground reach |
1.76m |
5ft9in |
2.93m |
9ft7in |
|
A |
Platform length-8ft model |
0.91m |
3ft |
0.91m |
3ft |
Platform length-6ft model |
0.76m |
2ft |
0.76m |
2ft |
|
B |
Platform width-8ft model |
2.44m |
8ft |
2.44m |
8ft |
Platform width -6ft model |
1.83m |
6ft |
1.83m |
6ft |
|
C |
Height-stowed |
2.7m |
9ft |
2.7m |
9ft |
D |
Length-stowed |
9.59m |
31ft |
10.69m |
35ft |
E |
Width |
2.49m |
8ft |
2.49m |
8ft |
F |
Wheelbase |
2.5m |
8ft |
2.5m |
8ft |
G |
Ground clearance-center |
0.43m |
1ft5in |
0.43m |
1ft5in |
PRODUCTIVITY |
|||||
Lift capacity (restricted) |
480kg |
1056lbs |
480kg |
1056lbs |
|
Lift capacity (non-restricted) |
340kg |
748lbs |
250kg |
551lbs |
|
Platform rotation |
160° |
160° |
|||
Jib rotation |
-- |
135° |
|||
Turntable Swing |
360°continuous |
360°continuous |
|||
Turntable tail swing |
1.19m |
4ft |
1.19m |
4ft |
|
Travel speed -stowed |
6.3km/h |
3.9mph |
6.3km/h |
3.9mph |
|
Travel speed -raised or extended |
1.3km/h |
0.8mph |
1.3km/h |
0.8mph |
|
Gradeability -stowed (2WD) |
30% |
30% |
|||
Gradeability -stowed (4WD) |
45% |
45% |
|||
Turning radius - inside |
3.0m |
9ft7in |
3.0m |
9ft7in |
|
Turning radius –outside Turning radius - axle extended outside |
5.2m |
16ft8in |
5.2m |
16ft8in |
|
Controls |
24V DC Proportional |
24V DC Proportional |
|||
Solid tires |
9.00-20 |
9.00-20 |
|||
POWER |
|||||
Power source |
Lovol 1004-4 78 hp (58kw) Perkins 400 61hp (45.5kw) Cummins B3.3NA-C60 4 60HP (45kw) |
||||
Auxiliary power unit |
24V DC |
24V DC |
|||
Hydraulic tank capacity |
190L |
190L |
|||
Fuel tank capacity |
150L |
150L |
|||
WEIGHT |
|||||
2WD |
13000kg |
28660lbs |
13140kg |
28968lbs |
|
4WD |
13080kg |
28836lbs |
13220kg |
29145lbs |
|
STANDARDS COMPLIANCE EN280, JG/T5101, Q/ADZV001-2008 |
ATTACK GLOBAL (HK) Co.,Ltd. is a professional articulated forklift manufacturer specializing in material handling machinery for more than 10 years. We produce and supply omni wheel forklift, forklift omni wheel, man lifter truck, manlift telescopic boom, articulated forklift truck, etc. Wantt o know more, contact us.
