The 500-1000 tph hard stone crushing plant
Quantité : 10 Prix : 9 999,00 €
The 500-1000 tph hard stone crushing plant can be used in limestone crushing equipment, stone blasting down from the mountains, through the dump will be less than 1020mm of stone into the feeder, vibrating feeder evenly into the stone jaw crusher, jaw crusher conducted on the first paragraph of broken stone, broken jaw out of stone from the 150mm -300mm or so, through the feeder into the European version of the material for the second paragraph of back-breaking broken through round vibrating screen sieving grading of materials, greater than the finished material back into back-breaking re-broken, finished by a belt conveyors to the finished product area.
Process Introduction:
When the production of 500-1000 tons of granite, basalt crushing equipment, stone blasting down from the mountains, through the dump will be less than 1020mm of stone into the feeder, vibrating feeder evenly into the stone jaw crusher, jaw crusher for crushing stone for the first paragraph, the broken jaw crushed stone at 150mm - 300mm or so, through the feeder material into efficient hydraulic cone crusher for second crushing, crushed material through the circle vibration sieve screening, more than 40mm of material re-return cone crusher crushing, 40mm below the material from the belt conveyor into shaping machine shaping. After shaping the finished circular vibrating sieve through screening by belt conveyors to the finished product area.
NO. |
Equipment |
Model |
Max. Feeding Size (mm) |
Motor(KW) |
Number |
|
I |
Vibrating Feeder |
GZD1500X6000 |
800 |
30 |
1 |
|
II |
Jaw Crusher |
PEW1100 |
940 |
185 |
1 |
|
III |
Vibrating Feeder |
GZG100-4 |
|
|
1 |
|
Ⅳ |
Cone Crusher |
CSB240(C) |
1650 (5 1/2')Dia. mm (feet) |
240 |
1 |
|
V |
Vibrating Screen |
4YZS2160 |
100 |
30 |
1 |
|
Belt: B500×10m, B1400×28m, B1200×36m, B1200&t imes;26m, B800×27m, B800×18m, B800×18m, B6500× ;15m, B650×15m |
crushing plant manufacturers: http://www.micrusher.com/index.html
http://micrusher.com/en/solution/stone-crushing-line.html
