The Uses of Long Pulsed ND YAG Laser in Dermatology

The ND YAG wavelength is a common wavelength used in dermatology, which is generated through the Neodymium-doped yttrium aluminium garnet crystal at a wavelength of 1064nm in the near-infrared range of the electromagnetic spectrum. The ND YAG as a wavelength is uniquely positioned in terms of the absorption coefficients of the three main chromophores in the skin (water, melanin, and haemoglobin), and it is this advantage that makes the long pulse laser machine popular as a treatment for multiple conditions that require targeting these chromophores. The effects on the skin depend partly on the pulse duration, which can range from a millisecond down to the ultrashort pulse duration in the picosecond domain. If you want to know long pulsed ND YAG laser price, feel free to contact us!

In this article, we discuss the uses of the long pulsed ND YAG laser, which is in the microsecond and millisecond range. Hair removal will not be discussed, but it is worth noting that this wavelength is the main wavelength used in hair removal in darker skin types, given its preferential deeper compared to the alexandrite laser and its relatively lower melanin absorption, which decreases the risk of epidermal injury. In lighter skin types, the ND YAG can also be used in tanned individuals for similar reasons.

Vascular uses:

As mentioned in the introduction, the ND YAG wavelength is absorbed by haemoglobin which is why this laser can be used for a number of vascular conditions in dermatology. In particular, venous lesions respond preferentially to the ND YAG compared to the shorter vascular wavelengths as they are located deeper in the skin and are rich in deoxyhaemoglobin which is well absorbed by the ND YAG wavelength. The combination of these two characteristics makes this wavelength the first choice for venous lesions, such as leg veins, venules on the face and thick or hypertrophic parts of haemangiomas, and port-wine stains.

Venules on the face respond well to the ND YAG and are safe to treat using a small spot and starting with low fluences, given the risk of atrophic scarring when a large spot size and high fluences are used. In one study comparing both the ND YAG laser against the pulsed dye laser (PDL) for nasal vessels, it was found that the small red telangiectasia responded better to the PDL, whereas the blue venules responded better to the ND YAG laser; an observation agreed with by laser experts.

A study on the comparison between the ND YAG long-pulsed laser against the 532nm vascular laser in leg vessels showed that the longer of the ND YAG wavelength was superior to the 532nm laser given the deeper uniform heating, which addressed the lower parts of the vessels since only the upper part of some vessels were in interaction with the shorter 532nm wavelength. The parameters of the ND YAG in leg vessels depend on the size and depth of the leg vessels, with typically smaller vessels requiring a smaller spot size and a shorter pulse duration and larger vessels requiring a slightly larger spot size (maximum 7mm) and a longer pulse duration. The clinical endpoint is important, which is colour change, spasm or disappearance of the vessel.

The gold standard treatment for port-wine stains remains the PDL, although there are reports of intense pulsed light (IPL) and 532nm treatment in this condition. The hypertrophic component of port-wine stains responds less well to the shorter wavelengths and is preferentially treated with the ND YAG wavelength. The hypertrophic blebs and the purple colour of the vessels imply larger calibre vessels located deep in the skin hence their response to the ND YAG laser. Indeed in a study among Chinese patients, it was demonstrated that for the purple component of the port-wine stain, the ND YAG was efficient, albeit it should be used with care and expertise.

The treatment of haemangiomas has been transformed over the last decade since the discovery of the efficacy of systemic beta-blockers in this condition. Nevertheless, the ND YAG laser has been used in combination with the PDL in the treatment of the deeper component of the haemangiomas with success.

Scars:

The use of lasers in the treatment of scars has been transformational over the last decade since it was found that fractional lasers remodel scar tissue and improve outcomes such as pliability, colour, and thickness. Vascular lasers play an integral part in laser scar therapy beyond just simply targeting the vascular component of the erythema. The ND YAG laser has been used in several studies in hypertrophic and keloid scars with demonstrable changes at a molecular level in the scar tissue, such as upregulating transforming growth factor beta 3 (TGF-b3) and reduction in collagen type. Treatment with the ND YAG should take into consideration the scar colour and thickness as well as the background skin type and is typically achieved with mid-spot sizes (4–7 mm) and fluences below the purpuric threshold. The use of microsecond pulse ND YAG has also been reported in scars, particularly in the treatment of atrophic scars.

An interesting finding in a study on keloids using the ND YAG laser is the benefit this wavelength has on the pain symptoms of a keloid. The attribute this to the deep of the wavelength which reaches the nerve plexus responsible for the pain sensation in some keloids. The use of the ND YAG laser in both hypertrophic and keloid scars is a subject of ongoing interest, with studies continuing to examine the utility of this wavelength in the field of scar management.

Warts:

The long pulsed ND YAG laser is very effective in the treatment of cutaneous warts and verrucae, and its use in this cutaneous infection has been published in several series, including among higher Fitzpatrick scale skin types in a study from Korea. One limitation of the treatment could be the relatively high pain sensation this treatment is associated with, but it has been demonstrated to clear cutaneous warts effectively, at times with as little as a single treatment session. Typical parameters would be a small spot size and a pulse duration of between 20 to 30ms, and relatively high fluences. It is thought that the mechanism of action is a combination of papillary vessel coagulation or necrosis together with clefting of the dermo-epidermal junction as a result of the thermal effect, a mechanism explaining the need for relatively high fluences. Overall the recurrence rate seems to be relatively low in this method of treatment, and therefore the ND YAG could be an excellent choice of treatment, particularly for resistant or multiple warts unresponsive to topical therapy.

Acne:

Acne vulgaris is a common inflammatory skin condition of the pilosebaceous unit. While there are established medical therapies in terms of topical and systemic therapy for this condition, patients with milder forms of acne are increasingly seeking laser treatment given their reluctance for medical therapy. The long pulsed ND YAG laser has been used in acne for many years, with several studies published on its efficacy in the mild to moderate forms of acne. Both the pulsed millisecond as well as the painting technique with the microsecond pulses have been used. The mechanism involves thermal effects on the sebaceous glands with a degree of microvessel coagulation and the generation of heat shock proteins that recreate a bactericidal effect against the c.acnes bacteria. Combination treatment with other established acne therapies may lead to faster response and synergism in response to treatment.

Rosacea/diffuse redness:

Papulopustular acne, as well as diffuse redness and vascular rosacea, have been successfully treated with the long pulsed ND YAG laser in both the millisecond pulsed mode as well as the painting mode with the microsecond pulse. As discussed earlier, the ND YAG wavelength is absorbed by haemoglobin hence its efficacy in diffuse redness due to the photothermal effects leading to vessel coagulation. Particularly the short pulse duration would be more suitable for the treatment of diffuse redness since the small vessel size would have a short thermal relaxation time. In one study among patients with papulopustular rosacea, the use of long-pulsed ND YAG led to good clearance of the majority of patients with no complications. In practice, the ND YAG laser can be combined with other topical or systemic therapies for rosacea for a synergistic effect.

Onychomycosis:

Fungal nail infection is a common problem worldwide, and while there are systemic treatments for this condition, the use of lasers might be an alternative for patients who are unable to or unwilling to take systemic treatment in the form of tablets. The long pulsed ND YAG has been reported in numerous studies to be effective in onychomycosis, with typically several treatments needed at around monthly intervals. There is some variation in terms of parameters — in particular, the pulse duration — but it is generally the short pulse durations in the nano and microsecond range that tend to be effective. The author prefers to use the microsecond pulse duration with a high repetition rate, with heat generation being the suggested mechanism behind its efficacy.

Hair follicle-related disorders:

In addition to laser treatment of hirsutism or unwanted hair for aesthetic reasons, the long pulsed ND YAG laser has been used in a number of follicle-related disorders with or without combination treatment with favourable outcomes. These conditions include hidradenitis suppurativa, pilonidal sinus (particularly post-surgery), dissecting cellulitis, keratosis pilaris, and pseudofolliculitis barbae.

Rejuvenation:

The long pulsed ND YAG laser, as mentioned previously, is a wavelength that is absorbed by all three main skin chromophores: haemoglobin, melanin, and water. The absorption by water is particularly enhanced in the short microsecond wavelength where there is little to no melanin and haemoglobin absorption, and with a high repetition rate there can be a build-up of heat in the skin that may eventually with repeated treatments lead to rejuvenation with texture improvement, pore tightening, and some tissue firming and rejuvenation. In some reports, the procedure uses long pulsed ND YAG in the millisecond range.

What To Expect During And After Your Long-Pulsed ND YAG Laser Treatment

The long-pulsed ND YAG laser is a popular cosmetic treatment for adults with vascular lesions, pigment irregularities, spider veins, and other skin concerns, like wrinkles and fine lines. The ND YAG laser, set in the long-pulsed mode, is safer for all skin types compared to all other YAG pulse durations.

*How Does The Long Pulsed ND YAG Laser Rejuvenate Skin?

The YAG laser uses an intense light that injures the targeted area by heating the tissue or subcutaneous skin. This injury stimulates your body's natural collagen growth response. Because collagen improves the skin's health and texture and as your body heals, the treated area will be smooth and tight once it is fully healed.

*How Does The Long-Pulsed ND YAG Laser Treat Vascular Lesions?

If we are using the YAG laser to treat vascular lesions, the laser will be targeted to enter the vein where the laser energy is then absorbed until the vein walls collapse which shuts the vein down. The vein will disappear immediately, or your body will absorb it over the course of 1-2 weeks following treatment.

*How To Prepare For Your Long-Pulsed ND YAG Laser Treatment?

If you have an upcoming long-pulsed YAG laser treatment, you should avoid direct sunlight for the 2 weeks prior to your appointment. Keep in mind, if you are sunburned or tanned, your treatment will need to be rescheduled.

*What To Expect During Treatment And After Treatment?

Typically, during a YAG laser treatment there is little discomfort. This minor discomfort is typically described as that of a “rubber snap” on your skin. After treatment, the treated areas are usually pink and sometimes mild swelling can occur, this will resolve within 1-2 days.

Vascular lesions can sometimes develop a gray or ‘charred' appearance which resolves within 1-2 weeks.

*Aftercare Instructions For Your Long-Pulsed ND YAG Laser Treatment

Avoid direct sunlight and use sunscreen to prevent hyperpigmentation of areas treated. Remember, your skin will be more sensitive after any laser treatment. Use an ice pack as needed to help with swelling and avoid strenuous activities for 48-72 hours after treatment. If a scab forms, avoid picking or any manipulation to area, and use Vaseline or an antibiotic ointment daily until healed. You can wear makeup immediately after treatment.

*How Many Long-Pulsed ND YAG Laser Treatments Are Needed?

Multiple treatments, typically 2-3, may be required to achieve your desired results. Treatments are typically anywhere from 4-6 weeks apart from each other.

Conclusion

The long pulsed ND YAG laser is a near-infrared wavelength that has the unique position of being absorbed by all three main skin chromophores: haemoglobin, water, and melanin. It has, therefore, multiple uses in dermatology, from vascular to hair removal and numerous other conditions such as scars, acne, and warts, to name just a few. The treatments can be combined with other modalities and may, in some cases, require several sessions. The ND YAG plays an important role in the field of laser dermatology, and ongoing interest in its uses are still being explored.
