Two-Part, 1 To 1 Mix Ratio Silicone Potting - 4313-AB
Quantité : 2000TON
FEATURES OF two part silicone adhesive, Ratio Silicone Potting - 4313-AB
Flammability,UL-94V0 certification
Excellent resistance to high and low temperature, weather, ultraviolet light and aging, excellent performance of insulation and thermal conductivity
two part silicone rubber , mixed color is W/G, low viscosity, good flowability, long working time, Rapid integrated curing speed, suitable for encapsulation of extensive module.
Superior heat curing feature allows a wide range of area and depth of sealing parts, smooth surface and out from within.
Description
GOLOHO-4313(W)-AB is a two part flame retardant additional thermal conductive encapsulant particularly designed for electrical industrial. It will form rubber elastomer non-corrosive to metal at room or low temperature .
HOW TO USE GOLOHO-4313-AB
Stirred thoroughly before mixing
Mixed in 1: 1 ratio by weight
Agitation: mixed thoroughly by low speed agitation
Foam scrubbing: evacuation for 5 minutes after mixing. Dispose it if a small amount of operation or no critical request of foam.
Encapsulation: pour into the article immediately after agitation and foam scrubbing thoroughly, it can flow flat naturally
Curing 1: curing at room temperature for 2.5 hours. The cure rate is rapidly accelerated with heat
Curing 2: curing by oven. After 30 min standing and foam scrubbing thoroughly and preliminary curing at room temperature, the encapsulant will be cured at 70℃ for 20 minutes
TECHNICAL DATA OF GOLOHO-4313-AB
Model |
GOLOHO-4302W(G)-AB |
|
Uncured |
A |
B |
Appearance |
White(grey), Flowing |
白色流动状White, Flowing |
g/cm3 Density |
1.60±0.1 |
1.60±0.1 |
Viscosity cP |
4000±500(25℃) |
4000±500(25℃) |
Mix ratio(weight/volume) |
1 |
1 |
Cured mechanical properties |
||
Working time (25℃)h |
1 |
|
Cure conditions |
|
|
Durometer JIS A |
50±5 |
|
Tensile strength MPa |
>1.0 |
|
Elongation % |
>70 |
|
Thermal conductivity W/m·K |
0.6~0.8 |
|
Flammability |
UL94V0 |
|
Electrical properties |
||
Volume resistivity Ω﹒cm |
>1×1014 |
|
Dielectric strength kV/mm |
20 |
OTHER CAUTIONS OF GOLOHO-4313-AB
Curing processing will be prevented if contact with condensed silicone rubber and gas released, N, P, S, heavy metal chemicals
Wear an eye-patch and gloves during operation, keep the environment be ventilated
Packaging: A, 25kg, B, 25kg
Storage: shelf life is 6 months when it stored in cool dry place under the condition of 22℃ and RH<55%. Keep out of the reach of children.</span>
Without notice, the contents of this article may be changed due to the product performance improvement and specification.
We just only ensure the specifications of our products. You have to test the product before using to conform if it is suitable for your use.
Our products are developed for general industrial use.
Please contact the company's customer service if you want to reprint the contents of the products. Customer service hotline: 0519-85610389
GOLOHO rtv grease is a safe thermal conductive silicone grease which is inodorous, non-poisonous, no corrosion to common materials
Goloho chemical is a leading enterprise in China which manufacture industrial adhesives
such as RTV silicone, grease and conformal coating. Which are widely used in new energy, rail transportation, photoelectric display, electrical electronic equipments. Want to know more, contact us.
