VERTICAL TURNING CENTER SPECIAL FOR WHEEL HUB

This cnc vertical turning machine tool takes the common 14-26 inch Kaba wheel hub rough and fine turning as the main processing object and has the advantages of high efficiency, uniform grain, stable performance, and so on.

FEATURES OF VERTICAL TURNING CENTER SPECIAL FOR WHEEL HUB SPECIFICATION

There are certain applications where a turning centre lathe has an advantage over other machining solutions. We take advantage of this to produce better parts and more efficient machine pieces.

Heavy workpieces are easily set up and held in place when machining. Gravity works with the machine to keep the part in place, and minimum clamping is required compared to other processes. Our cnc processing center can accomplish this while taking up less space than a comparable horizontal lathe would.

VTLs that have the main spindle load and unload themselves are able to multitask when machining and producing chucked parts, reducing machining times and turnaround for our customers.

Our vertical lathes accommodate bigger and heavier castings within our shop than a horizontal lathe would. We are able to take heavier cuts safely without messing up our tolerances. This cuts down on cycle times because we can more aggressively remove material. We can control the final surface finish from semi-finished to fine, giving our clients excellent results right off the machine without any grinding required.

The rotating table supports the workpiece. A precision ram drives the x-axis and delivers the cutter to the desired location.

There is high quality vertical turning lathe for sale，and we can provide competitive vertical turning lathe price for you.

VERTICAL TURNING CENTER SPECIAL FOR WHEEL HUB SPECIFICATION

Vertical Turning Center Special For Wheel Hub

project parameter

Rotation diameter φ900

Cutting diameter φ730

Machining height 350

X axis X1 (left) outer rim 0~480

X2 (right) inner rim -40~440

Z1 and Z2 axes 0~540

principal axis speed 2500rpm

Nasal end A2-11

Shaft diameter φ180mm

power 55/65kw

Feed servo 快速进给 20m/min

型号 aiF22-3000(X1、X2)aiF22B-3000(Z1、Z2)

Overall dimension (length) × wide × High) 3552×2991×3384 mm

Machine weight about 21t
