Vietnam Drip Coffee Bag Packing Machine with Outer Envelope
Quantité : 300 sets p Prix : Negotiable
l Application:
It is suitable for 5 to 15gram drip coffee inner and outer bag packaging.
l Features:
1. Outer bag sealing is controlled by the stepper motor, ensuring accurate and stable bag length positioning.
2. Adopts PID temperature controller for more accurate temperature adjustment.
3. Adopts PLC control system and touch screen color monitor device, machine is very easy to operate.
4. The main machine parts is made of SUS304 stainless steel, so it ensures hygiene products output.
5. Some cylinders are imported, ensuring the accuracy and stability of the machines' performance.
6. It can make the inner and outer bag at the same time automatically, which would highly improve the working efficiency.
7. Adopts automatic conveyor system.
8. Leaving a reserved connector to link with nitrogen making machine, which can flush nitrogen into the bag to keep coffee fresh.
9. Options: Date code printer.
l Standard Technical Data
|
Machine type: |
Drip Coffee Packaging Machine Series |
|
Machine model: |
C19II |
|
Machine name: |
Automatic Drip Coffee Bag Packing Machine with Outer Envelope |
|
Sealing method: |
Inner: 3 sides sealing; Outer: 3/4 sides sealing |
|
Packing material: |
Paper/Plastic, Plastic/Aluminum/Plastic, Paper/Aluminum/Plastic, Filter paper |
|
Feeding system: |
Measuring cup filler |
|
Package range: |
5-15g |
|
Inner bag size: |
L: 50-75mm , W: 50-90mm |
|
Outer bag size: |
L: 85-120mm , W: 75-100mm |
|
Inner bag film width (180mm): |
Bag size: L90mm*W75mm |
|
Outer bag film width(200mm): |
Bag size: L120mm*W100mm |
|
Power supply: |
Single phase, 220V, 50HZ, 3.7KW |
|
Packing speed: |
40-60bags/min |
|
Machine weight: |
400KGS |
|
Machine dimension: |
1200*900*1900mm(L*W*H) |
Personne à contacter : Andy Zhong, +86 592 5523433
