VZSB Series – ATEX Heavy Duty Industrial Vacuum Cleaner
VZSB Series are atex approved vacuum cleaners with high pressure, very ideal for sucking/absorbing large mixed particles or chips in continuous applications or installed to centralized extraction systems.
Parameters of VZSB Series – ATEX High Pressure Industrial Vacuum Cleaner
|
Model |
VZSB-20 |
VZSB-34 |
VZSB-52 |
|
Voltage(V / Hz) |
230 / 50 |
400 / 50 |
400 / 50 |
|
Power (kW) / (HP) |
2.0 / 2.7 |
3.4 / 4.6 |
5.2 / 7.0 |
|
Starting current （A） |
55 |
50 |
90 |
|
Rated current（A） |
13 |
8 |
10 |
|
Max vacuum (mmH₂O) / (kPa) |
1200/16.6 |
2000/19.7 |
2000/19.7 |
|
Noise dB (A) |
72±2 |
78±2 |
78±2 |
|
Dia. air inlet (mm) / (in) |
Ø 50 / 2 |
||
|
Filter area(m²)/ (sq.ft) |
3.0 / 32.3 |
||
|
Filter efficiency |
>99% |
||
|
Capacity of collection barrel (L) / (gal) |
100 / 26.4 |
||
|
Dimension [L*W*H] (mm) / (in) |
1350*880*1500 / |
||
|
Weight(kg)/ (lb) |
130 / 286 |
150 / 330 |
180 / 397 |
|
It is normal that the current value may fluctuate in a small range |
|||
Features of VZSB Series – ATEX Heavy Duty Industrial Vacuum Cleaner
Customizable voltage
Power less than or equal to 2.2 kilowatts can be made into single phase.
ATEX certified for Zone 22
Maintenance free powerful turbine motor can work continuously for 24 hours.
Equipped with filter cleaning device for easy filter cleaning.
Pressure gauge to detect filter clogging
Easy dust container cleaning
Applications of VZSB Series – Atex Rated Vacuum Cleaner
Suitable for single/ three phase working condition
Suitable for continuous working and heavy dust with explosion proof requirement.
Industries: Metal Processing (grinding, cutting, drilling, etc.)
Wood Working
Food Industry
Chemical Industry
Machine Cleaning
Active Metal（Aluminum, Magnesium，Titanium） Polishing
Now the price of china dust removal equipment is reasonable, if you have needs to buy dust vacuum industrial products, please contact us.
