Wattage adjustable and color tunable flat panel light
Quantité : according Prix : 10-100USD
Wattage adjustable & color tunable led flat panel light.
Visual Uniformity.
High efficiency up to 130LM/W, Premium version for optional.
Flicker free LED drive.
Features
LED flat panel light is the latest new generation of edge-lit lighting fixture,it has the uniform and smooth lighting effect and elegant appearance design. And each fixture is 15 SKUS in 1 unit design,so the users can easily set the wattage and color temperature that they want.
1. Wattage adjustable & color tunable led flat panel light.
One piece wattage adjustable and color tunable panel light=15 pcs regular panel light now,it can save the shipping time,warehouse space and your stock cost.
2. Visual Uniformity.
Using high quality LGP with silk printing technology, the light uniformity rate is greater than 85%. No yellow edge and dark area,prefect lighting effect.
3. High efficiency up to 130LM/W, Premium version for optional.
High transmission LGP (more than 90%), high lumen LED efficacy paired with high power factor drivers.
4. Flicker free LED drive.
Constant current design,PF>0.9,THD<15%. 3 in 1 dimming mode: 0-10V,PWM,Rx Smoothly dimming 0-100%,can dim to off Short circuit,open circuit protection,and 1KV surge protection.<br />
5. Three installation options.
Each panel with standard clips for recessed and suspending installation.Optional surface mounted kit available.
Parameter
|
Model |
CCT |
Light efficiency |
Size(feet) |
Power |
LED type |
Voltage(V) |
CRI |
Color tunable selectable way |
|
2X2 105LMW panel light |
3500K-4000K-5000K |
105LM/W |
2*2 1*4 2*4 2*4 |
20W/25W/30W/35W/40W 20W/25W/30W/35W/40W 30W/35W/40W/45W/50W 40W/45W/50W/55W/60W |
4014 |
100-277VAC |
>80 |
DIP switch |
|
2X2 130LMW panel light |
3500K-4000K-5000K |
130LM/W |
2*2 1*4 2*4 2*4 |
20W/25W/30W/35W/40W 20W/25W/30W/35W/40W 30W/35W/40W/45W/50W 40W/45W/50W/55W/60W |
4014 |
100-277VAC |
>80 |
DIP switch |
|
2X2 130LMW panel light |
3500K-4000K-5000K |
105LM/W |
2*2 1*4 2*4 2*4 |
20W/25W/30W/35W/40W 20W/25W/30W/35W/40W 30W/35W/40W/45W/50W 40W/45W/50W/55W/60W |
4014 |
100-277VAC |
>80 |
Wall switch (Standard 0-10V dimmer) |
|
2X2 130LMW panel light |
3500K-4000K-5000K |
130LM/W |
2*2 1*4 2*4 2*4 |
20W/25W/30W/35W/40W 20W/25W/30W/35W/40W 30W/35W/40W/45W/50W 40W/45W/50W/55W/60W |
4014 |
100-277VAC |
>80 |
Wall switch (Standard 0-10Vdimmer) |
Dimensions (unit: feet):
Download
|
Name |
Update date |
Document |
Download |
|
Specification of Wattage Adjustment and Color Tunable Flat Panel Light |
2019.10.29 |
1.09MB |
|
Signcomplex Ltd. is a state-level high-tech company. We provide customers with led sign lights waterproof products. We additionally have a trained QC group to ensure the great of all the products of led light.
