Wind solar hybrid generator

Model

EC500W

EC800W

EC1.3KW

EC2.6KW

EC4KW

EC6.8KW

EC13KW

EC26KW

EC40KW

RatedPower ofWindSolar System

500W

800W

1300W

2600W

4000W

6800W

13KW

26KW

40KW

Wind Turbine Generator Main Data

RatedPower ofWind Turbine(W)

400

600

1000

2000

3000W

5000W

10KW

20KW

30KW

OutputVoltage(V)

24

24

24/48

48/120

48/120

240

240

240

240

Rotor Diameter(m)

1.5

1.6

2.7

3.2

3.7

6.2

8

10

12

Startup Wind Speed(m/s)

2.5

2.5

2.5

2.5

2.5

2.5

2.5

2.5

2.5

RatedWindSpeed(m/s)

9

10.5

12

12

11.5

12

10

12

12.5

SecurityWind Speed(m/s)

45

45

45

45

45

45

45

45

45

RatedRotatingRate(r/m)

450

400

400

400

400

220

180

90

75

BladeMaterial

CarbonFiberComposite

GFRP

GFRP

GFRP

GFRP

GFRP

GFRP

GFRP

ShellMaterial

Aluminum

Alloy

Aluminum

Alloy

Aluminum

Alloy

Aluminum

Alloy

Aluminum

Alloy

Aluminum

Alloy

Aluminum

Alloy

Aluminum

Alloy

Aluminum

Alloy

BladeQty.

3

3

3

3

3

3

3

3

3

Guy Cable

tower

Tower Height

(m)

6

6

6 (9mfor

option)

9

9

12

/

/

/

Hydraulic

Tower

Tower Height

(m)

/

/

8 (12 for

option)

8 (12 for

option)

8 (12 for

option)

12

12

18

18

Solar Panel Data

TotalPower ofSolar Panel

(W)

100

200

300

600

1000

1800

3000

6000

10000

Power ofeachPanel

(W)

50

100

75

100

100

180

170

170

185

QtyofPanels

(pcs)

2

2

4

6

10

10

18

36

54

Suggested battery capacity

12V150Ah

2PCS

12V200Ah

2PCS

12V200Ah

4PCS

12V200Ah

10PCS

12V200Ah

20 PCS

12V200Ah

30 PCS

12V200Ah

40 PCS

12V200Ah

90 PCS

12V200Ah

90 PCS

Charging Controller

IntelligentIntegrated WindSolar HybridController (LCD Display)

Inverter

Pure SineWave Inverter

Standard Supply Scope

Complete System including Solar Panels, Stand Array, WindTurbine, Blades,Controller,Inverter, Tower,CablesandOtherAccessories.
