YZYX120ZHWK Centrifugal Automatic Temperature Controlled Combined Oil Press
YZYX120ZHWK combined oil press with centrifugal combines with the centrifugal oil filter above the basic function of auto-heating the press cage by replacing the traditional manual wearing in way. The crude oil from the press cage will directly flow into the hydration cylinder of centrifugal oil filter. This machine is easily operated with better working efficient.
Main equipment parameters of YZYX120ZHWK Centrifugal Automatic Temperature Controlled Combined Oil Press
Model |
Processing Capacity(T/24H) |
Oil Press Power(KW) |
Filtration Power(KW) |
Temperature Control Power(KW) |
Oil Content of Dry Cakes(%) |
Spiral Axes Rotate Speed(r/min) |
Measurement(L*W*H)(mm) |
Weight(kg) |
YZYX120ZHWK |
6.5 |
11 |
|
3.2 |
≤7.6 |
32-40 |
2130*1350*1940 |
1080 |
YZYX120ZHWK centrifugal automatic temperature controlling combined oil press is developed on the basis of the single machine to meet the market demands. The function of auto-heating the press cage has replaced the traditional way by squeezing residue cake, which could shorten the preparation work, reduce the energy consumption and abrasion, and thus lengthen the durability. When the squeezing is suspended, the temperature can be maintained by this system. In the meanwhile, this machine was added with centrifugal filtration function. The crude oil discharged from the press cage will directly flow into the hydration cylinder of centrifugal oil filter (if the oil needs to be cooled, start the stirring function of the centrifugal filter). Once the oil volume reaches the capacity of centrifugal for one time or twice work, it will close the valve of oil collection pan, and start hydration of oil in hydration cylinder, then filtration with the centrifugal filter. The oil after filtration can be bottled.
The press machine and multifunctional oil filter can be used in combination or separately for single use.
YZYX120ZHWK is the three steps press combined oil press, the pressure is stronger, with which user can obtain more excellent economic benefits.
Main Features of YZYX120ZHWK Centrifugal Automatic Temperature Controlled Combined Oil Press
Below features are based on oil plants above the average quality smoothly and continuously squeezed after such pretreatments as screening, husking, flaking, and cooking, etc.
Oil Plants |
Processing Capacity(t/24h) |
Oil content of |
Oil yield |
Electricity consumption(kW·h/t) |
Rapeseed |
≥6.5 |
≤7.6 |
≥82 |
≤40 |
Cotton seeds |
≥6.5 |
≤6.8 |
≥77 |
- |
Soybean |
≥5.5 |
≤6.5 |
≥67 |
≤56 |
Groundnut |
≥6.5 |
≤6.5 |
≥92.3 |
≤39 |
The day capacity (t/24h) is based on using hot way to squeeze one time. The more the squeeze times are, the lower the date capacity is.
Applicable oil plants and Business of YZYX120ZHWK Centrifugal Automatic Temperature Controlled Combined Oil Press
1. More than 30 types of oil plants, such as rapeseed, cottonseed, soybean, shelled peanut, flax seed, sunflower seed, and palm kernel, etc.
2. Uses in oil factory, oil mill, and privates oil production workshop.
3. Good both for pressing raw oil material and roasted oil material.
4. Performs well both in cold pressing and hot pressing.
5. The lower residue oil of the dry cake.
The product conforms to the "Technology Standard of Agricultural Spiral Oil Press" under JB/T9793-2013 of the People's Republic of China.
