Z101017 HD 7 Inch TFT LCD 12001920 QVGA MIPI Interface OTA7290B Controller
Size: 10.1 inch
Resolution: 1200*1920
Active Area: 135.36*216.58mm
Interface: MIPI
View Angle: IPS
Brightness: 400 cd/m²
Touch Panel: Support CTP/RTP
Supply Type: Factory/Manufacturer
Certification: ISO9001, IATF16949, ROHS, REACH
Overview of Z101017 HD 7 Inch TFT LCD 1200*1920 QVGA MIPI Interface OTA7290B Controller
1
Z101017 is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) with 1200*1920 resolution. IPS (In-plane Switching) technique make this 10.1" LCD module have a wider view angle. This LCD display is built-in OTA7290B driver IC. This a-Si TFT LCD module come with MIPI interface, 400cd/m² brightness.
2
If you have special requirements, like drive IC, interface, FPC, touch panel, brightness, color, backlight, touch panel, etc, we can also customize for you.
3
Our factory carry out ISO 9001: 2015 and IATF16949: 2016 quality standard system strictly, all the LCD display passed ROHS, REACH Certification.
4
The 10.1 inch TFT LCD is widely used in Medical, visual doorbell, vending, learning mechine, ventilator, oscilloscope, kitchen, household appliance, smart home, industry, handheld, outdoor, E-bike, Vehicle, projector, 3D printer, audio device, robot, electric scale, navigation, dashboard, elevator advertising, laptop, HMI, education, etc.
Specifications of HD 7 Inch TFT LCD 1200*1920 QVGA MIPI Interface OTA7290B Controller
Item |
Main Display |
Unit |
Number of Pixels |
1200 * RGB * 1920 |
Pixel |
LCM Outline Dimension |
143.10 (W) * 228.60 (H) * 2.6 (T) |
mm |
LCD Outline Dimension |
140.40 (W) * 225.35 (H) * 0.8 (T) |
mm |
Active Area |
135.36 x 216.58 |
mm |
Pixel Pitch |
37.6 x 112.8 |
um |
Display Mode |
Normal Black |
|
Pixel Arrangement |
RGB-stripe |
|
Viewing Direction |
FREE |
|
Color Configuration |
RGB |
|
LCD Transmittance |
Typ: 4.04%; Min: 3.53% |
|
LCD Contrast Ratio |
Typ: 1000; Min: 800 |
|
FPC Version |
Z101017-P31F V1 |
|
Interface |
MIPI |
|
Operating Temperature |
-10℃ ~ 60℃ |
|
Storage Temperature |
-20℃ ~ 70℃ |
|
Backlight arrangement |
LED / 4 series 7 parallel |
|
Luminance |
- |
|
Weight |
- |
|
As a professional lcd display company, Zhunyi has high-quality china lcd module for sale. Welcome to contact us if needed.
