2.5 Inch Medical Capsule Low Black Steel Back Entry Low Pressure Indicator With U-Clamp

2.5 inch diameter low pressure gaue, steel material, back connection with u-clamp, suitable for the low pressure equipment.

Specifications of 2.5 Inch Medical Capsule Low Black Steel Back Entry Low Pressure Indicator With U-Clamp

Dial:

1.5"(40mm),2.5" (63mm),3”(75mm), 4” (100mm), and 6” (150mm)

Range:

1.5",2.5": 2.5KPa ~ 100KPa

3",4": 1KPa ~ 100KPa

6": 0.25KPa ~ 100KPa

Accuracy Class:

2.5": 2.5%

3",4",6": 1.6%

Case:

black steel(plated optional), 304SS nature color(polish optional)

Lens:

Polycarbonate, 3mm instrument plain glass

Measurement elements:

Standard copper alloy double diaphragm tin welding:

Stainless steel corrosion proof SUS316 double diaphragm plasma

welding and lasing welding.

Socket:

Copper alloy, corrosion proof SS304

Connection:

NPT standard

Movement:

Standard copper alloy, corrosion proof SS316 stainless steel

all withmicro adjustment devise (without zero adjustment option)

Pointer:

Aluminum

Working Pressure:

75% of full scale value

Over-Pressure Limit:

30% of full scale value

Ambient Temperature

-40°F to 150°F (-40°C to 65°C)

Enclosure Rating

IP54

As one of the most professional pressure gauges suppliers, we provide dry gauge, u clamp pressure gauge, china hydraulic gauges, etc. Contact us to know more.
