240W 24V 8A Battery Charger
Typical output: battery charger 24v 8a
Fully auto 4 stages charging process by MCU controller
4 LED indicate the battery capacity from 25%~100%
Worldwide AC input 100V-240V
Charging stage: Small current pr-charge; constant current charging; Constant voltage charging
The Specifications Of 240W 24V 8A Battery Charger
|
Charger Model |
AC Input Voltage |
Battery Voltage |
Max Voltage(V) |
Max Current (A) |
|
|
AP-PN240CH01460160 |
100-240 |
12 |
14.6 |
16 |
|
|
AP-PN240CH02920080 |
100-240 |
24 |
29.2 |
8 |
|
|
AP-PN240CH04200060 |
100-240 |
36 |
42 |
6 |
|
|
AP-PN240CH05460040 |
100-240 |
48 |
54.6 |
4 |
|
|
AP-PN240CH01200160 |
100-240 |
12 |
14.7 |
16 |
|
|
AP-PN240CH02400080 |
100-240 |
24 |
29.4 |
8 |
|
|
AP-PN240CH03600060 |
100-240 |
36 |
44.1 |
6 |
|
|
AP-PN240CH04800040 |
100-240 |
48 |
58.8 |
4 |
|
|
INPUT |
AC Input Voltage Range |
100V ~ 240V |
|||
|
AC Input Frequency |
45~65HZ |
||||
|
AC Power Factor Correction |
≥0.98 |
||||
|
OUTPUT |
Output Voltage Range |
12~60V |
|||
|
Output Power Range |
16A（Max） |
||||
|
VIBRATION |
10～50HZ 2G 10 minutes，X，Y，Z /60 minutes |
||||
|
DIMENSIONS(mm) |
(L)203х(W)81х(H)47.5 |
||||
|
Protections |
Over current protection ,Over Voltage Protection ,Short- circuit Protection Reverse Connection Protection ,Battery open-circuit protection |
||||
|
CERTIFICATIONS |
CE ROHS |
||||
|
PACKING DETAILS |
1.2kg/pcs 1pcs/Carton Carton size: 203*81*47.5mm |
||||
Shen Zhen Shi Alrightpower Technology Co., Ltd is a professional 5v 2a charger supplier, we provide 180w power adapter, portable usb charger, industrial power adapter and etc. For more information, please feel free to contact us!
