5.5V High Temperature Series
Kamcap is devoted to the research and development of ultracap and strictly control the ultracapacitor production. Kamcap super capacitor, your best choice for supercapacitor!
5.5V High Temperature Series
Kam also has 5.5v high temp capacitors for sale. The following information can help you know more about this ultracapacitor series.
Technical data
HT Series
Performance characteristics: High temperature 85 ° C series
Typical applications: RAM, detonator, car recorder, smart meter, vacuum switch, digital camera, motor drive, clock circuit, UPS, toy, program-controlled switch, etc.
Series specification sheet
|
Series name |
HT Combined series |
|
Type name |
HT-5R5 |
|
Rated voltage VR |
5.5V |
|
Surge voltage |
5.8V |
|
Capacity range |
0.5F~10F |
|
Operating temperature range |
-40 ~ +85℃ |
|
Product life |
Normal temperature cycle life: 25 ° C, VR to 1/2 VR cycle 1 million times, capacity attenuation ≤ 30%, internal resistance change ≤ 4 times |
|
High temperature endurance life: 85 ° C, keep VR, 1000 hours. Capacity attenuation ≤ 30%, internal resistance change ≤ 4 times |
HT -5R5(Connection plate)
|
Model |
Capacity F |
ESR mΩ |
Product size (mm) |
||||
|
DC |
AC 1kHz |
Width |
Length |
Height |
Pitch |
||
|
HT-5R5-Z334VYL06 |
0.33 |
2200 |
1100 |
8.5 |
16.5 |
15 |
12 |
|
HT-5R5-Z474TYL16 |
0.47 |
2200 |
1100 |
7 |
13.5 |
12 |
9 |
|
HT-5R5-Z474VYL06 |
0.47 |
1200 |
600 |
8.5 |
16.5 |
15 |
12 |
|
HT-5R5-Z105VYL07 |
1.00 |
960 |
480 |
8.5 |
16.5 |
22 |
12 |
|
HT-5R5-Z155VYL07 |
1.50 |
560 |
280 |
8.5 |
16.5 |
22 |
12 |
|
HT-5R5-Z155VYL13 |
1.50 |
560 |
280 |
10.5 |
20.5 |
22 |
15.3 |
|
HT-5R5-Z205VYL13 |
2.00 |
400 |
200 |
10.5 |
20.5 |
22 |
15.3 |
|
HT-5R5-Z205VYL09 |
2.00 |
360 |
180 |
13 |
25.5 |
23 |
17.8 |
|
HT-5R5-Z255TYL07 |
2.50 |
360 |
180 |
8.5 |
16.5 |
22 |
12 |
|
HT-5R5-Z255VYL13 |
2.50 |
360 |
180 |
10.5 |
20.5 |
22 |
15.3 |
|
HT-5R5-Z255UYL04 |
2.50 |
360 |
180 |
8.5 |
16.5 |
26 |
12 |
|
HT-5R5-Z305VYL13 |
3.0 |
300 |
150 |
10.5 |
20.5 |
22 |
15.3 |
|
HT-5R5-Z355VYL09 |
3.50 |
280 |
140 |
13 |
25.5 |
23 |
17.8 |
|
HT-5R5-Z355UYL13 |
3.50 |
280 |
140 |
10.5 |
20.5 |
22 |
15.3 |
|
HT-5R5-Z405VYL09 |
4.0 |
240 |
120 |
13 |
25.5 |
23 |
17.8 |
|
HT-5R5-Z505UYL11 |
5.0 |
240 |
120 |
10.5 |
20.5 |
27 |
15.3 |
|
HT-5R5-Z505VYL09 |
5.0 |
220 |
110 |
13 |
25.5 |
23 |
17.8 |
|
HT-5R5-Z505VYL10 |
5.0 |
220 |
110 |
13 |
25.5 |
27 |
17.8 |
|
HT-5R5-Z505VYL12 |
5.0 |
220 |
110 |
10.5 |
|||
