FBG ID REFLECTOR
FBG ID Reflector
FBG Reflector can be used in FTTX fiber trouble-shooting monitoring. The combination of the OTDR and FBG Reflector can detect and locate fiber faults in minutes, protect investment of unused fibers, and reduce the cost of maintenance.
FBG Reflector is one of the two solutions under U-band Reflector (The other is Thin Film based TFR, and both the two are available at T&S.). FBG Reflector has been granted China patent and US patent. According to the standard ITU-T G.982, reflectance of any optical component between ONU and OLT should be better than -35dB, which makes FBG Reflector a perfect solution.
T&S FBG reflectors are designed in different encapsulation forms to fit different applications. Customized encapsulations are also available.
Features of FBG ID Reflector
A Chirped FBG Embedded
IL<1db and="" rl="">35dB at Pass Band
Comply with ITU-T G.982
Stable and Reliable
Specifications of FBG ID Reflector
|
Parameters |
P/S |
Min |
Typical |
Max |
|
Pass Band (nm) |
- |
- |
1260 - 1625 |
- |
|
Reflect Band (nm) |
- |
- |
1645 - 1655 |
- |
|
IL (1260nm – 1360nm) (dB) |
P/S |
- |
- |
1.0/1.5 |
|
IL (1460nm – 1600nm) (dB) |
P/S |
- |
- |
1.0/1.5 |
|
IL (1600nm – 1625nm) (dB) |
P/S |
- |
- |
3.0/3.4 |
|
IL @ Reflect Band |
- |
21 |
- |
- |
|
RL (1260nm – 1360nm) (dB) |
P/S |
35/30 |
- |
- |
|
RL (1460nm – 1580nm) (dB) |
P/S |
33/28 |
- |
- |
|
RL (1580nm – 1620nm) (dB) |
P/S |
25/25 |
- |
- |
|
RL (1620nm – 1625nm) (dB) |
P/S |
20/20 |
- |
- |
|
RL @ Reflect Band (dB) |
- |
- |
- |
1.0 |
|
Max Optical Power (dBm) |
|
27 |
- |
- |
|
Plug Times |
- |
500 |
- |
- |
|
Operation Temperature (℃) |
- |
-25 |
- |
70 |
|
Operation Humidity (RH) |
- |
5 |
- |
95 |
|
Storage Temperature (℃) |
- |
-40 |
- |
85 |
|
Connector |
SC, LC |
|||
T&S Communications is a professional fiber optic products supplier. We provide WDMs, Fiber Optic Component, fiber optic reflector, fiber reflector and so on. Want to know more? Please contact us.
