Hard Rock PDC cone bit Used for drill underground core
Overview of PDC Core Bit
GREAT customized made Diamond core bits, which including Matrix body and Steel body, the Diamond core bit is used to drill an underground core (or mineral core) primarily when samples of underground rock (minerals) are required.
Every PDC Core bit is optimized hydraulically for each cutting structure and formation application.
Each design is based on a balanced and fully covered cutting structure.
Sometimes we need to analyze the rock, so the best choice asking GREAT salesman to get your right recommendation.
The Specification of PDC Core Bit
Bit Size and Type |
8 1/2"GMC3232 |
Nozzle Qty |
12P |
Cutter Size (mm) |
Φ13mm ×30 |
Gauge Lenghth |
1.8" |
Blade |
12 |
Connection |
Chuan 7-4 |
Operating Parameters |
|||
Rotary Speed(rpm) |
40~150 |
Weight on Bit(KN) |
40~80 |
Max.WOB(KN) |
90 |
Flow Rate(lps) |
10~30 |
The Advantage of PDC Core Bit
The PDC Core bit has design a shallow parabolic profile and medium cutter density, designed for coring the medium hard formation. Nozzles options according to the hydraulic request, it is installing the size of the mainly PDC cutter is 1308mm, and the most popular blade is 6 blade, 7 blade, 8 blade, enhance the bit's ability to drill in hard formations. Special TSP gauge or PDC Arc-cutters to protection the diameter.
The superior patented tool testing method provides the best PDC cutter for any challenge.
Soft to medium-hard formation with low compressive strength interbedded with hard layers.
Rock type: Mudstone, limestone, anhydrite.
Great Drill Bits is a professional drill bit manufacturers in china, we provide PDC Bit, Hybrid Drill Bit, Tricone Bit, Roller Bit, PDC Hole Opener, Crocodile PDC Reamer, button bit drilling, rock core drill bits, rock hammer drill bits, rotary hammer drill bits for rock and etc. Want to know about bits of rock? Please contact us.
