OF Series Outdoor Commercial Advertising LED Display
OF Series led commercial advertising display screen is a traditional outdoor LED digital billboard product, including large commercial advertising led display, mainly used for commercial advertising. It is a great way to promote business, meantime the concept of Smart City becomes more and more popular, large advertising screens can also be used as traffic instruction and information announcement board.
Product Features:
Weatherproof Design
Working temperature from -20℃ to +65℃. IP65 ensures water and dust proof.
Energy Saving Solution
Special PCB design and power supply option can save about 20% energy.
CLOUD Control
Suitable for over 90% of screen management scenarios, complete functions, and easy to use.
High Brightness
From 5,000nits to 12,000nits, face to sunshine directly without compromising performance.
Wide Viewing Angle
Vertical and horizontal 160 degrees promise perfect viewing effect.
Specification
|
OF/OFR |
OF2.5 |
OF3 |
OF3.076 |
OF3.91 |
OF4 |
OF4.81 |
OF5 |
|
Pixel Pitch(mm) |
2.5 |
3 |
3.08 |
3.91 |
4.00 |
4.81 |
5.00 |
|
Pixel Matrix Per Sq.m |
160000 |
111111 |
105680 |
65436 |
62500 |
62500 |
40000 |
|
Pixel Configuration |
SMD1415 |
SMD1415 |
SMD1415 |
SMD1921 |
SMD1921 |
SMD1921 |
SMD1921 |
|
Brightness (nits) |
5000 |
1800 |
5000 |
4000 |
5000 5500 |
4000 |
5500 |
|
Scan |
1/16 |
1/16 |
1/13 |
1/16 |
1/10 / 1/8 |
1/13 |
1/8 |
|
Module Dimension |
160x160mm |
192x192mm |
320x160mm |
250x250mm |
320x160mm |
250x250mm |
320x160mm |
|
Cabinet Dimension |
960x960mm （Cabinet size can be changed according to module size） |
||||||
|
Cabinet Weight |
46kg / 101lb (Iron) |
46kg / 101lb (Iron) |
45kg / 99lb (Iron) |
44kg / 97lb (Iron) |
44kg / 97lb (Iron) |
43kg / 95lb (Iron) |
43kg / 95lb (Iron) |
|
Power Con. (Max / Avg) |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
|
IP Rate |
IP65 |
||||||
|
Service Access |
Rear |
||||||
|
Refresh Rate (HZ) |
>1920 |
||||||
|
Grey Scale (bit) |
16bit |
||||||
|
Viewing Angle (H/V) |
140/140 |
||||||
|
Input Voltage (AC) |
110V/240V |
||||||
|
OF/OFR |
OF6 |
OF6.6 |
OF8 |
OF10S |
O10D |
OF16S |
OF16D |
|
Pixel Pitch(mm) |
6 |
6.67 |
8 |
10 |
10.00 |
16 |
16.00 |
|
Pixel Matrix Per Sq.m |
27777 |
22500 |
15625 |
10000 |
10000 |
8000 |
10000 |
|
Pixel Configuration |
SMD3535 |
SMD2727 |
SMD3535 |
SMD3535 |
DIP346 |
SMD3535 |
DIP346 |
|
Brightness (nits) |
5500 |
5500 |
6500 |
6500 |
10000 |
8000 |
10000 |
|
Scan |
1/8 |
1/6 |
1/3 |
1/2 |
1/2 |
1/1 |
1/1 |
|
Module Dimension |
192x192mm |
320x160mm |
320x160mm |
320x160mm |
320x160mm |
256x256mm |
256x256mm |
|
Cabinet Dimension |
960x960mm （Cabinet size can be changed according to module size） |
||||||
|
Cabinet Weight |
42kg / 93lb (Iron) |
42kg / 93lb (Iron) |
41kg / 90lb (Iron) |
40kg / 88lb (Iron) |
40kg / 88lb (Iron) |
46kg / 101lb (Iron) |
46kg / 101lb (Iron) |
|
Power Con. (Max / Avg) |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
900/ 180 w/sq.m |
|
IP Rate |
IP65 |
||||||
|
Service Access |
Rear |
||||||
|
Refresh Rate (HZ) |
>1920 |
||||||
|
Grey Scale (bit) |
16bit |
||||||
|
Viewing Angle (H/V) |
140/140 |
||||||
|
Input Voltage (AC) |
110V/240V |
||||||
* Specifications and photos are subject to change without prior notice.
As one of the most professional outdoor led screen manufacturers, we provide HD LED panel, pole LED display, outdoor LED advertising, outdoor led advertising display, large led advertising screens, large outdoor advertising screen, led display screen for advertising outdoor and etc. Contact us to know more.
