Thermally Conductive Silicone Rubber
GA-96*0 series thermal conductivity silicone rubber have good thermal conductive property, excellent heat transfer performance.
Silicone rubber thermal properties
GA-96*0 Series Heat Cure Rubber
Feature: good thermal conductive property, good processability among thermally conductive rubbers
Heat Conductive Silicone Rubber Application: thermal conductive gasket, rubber strip, thermal conductive sheath, thermal conductive silicon cloth
Typical Characteristics
Product code |
GA-9630 |
GA-9640 |
GA-9650 |
GA-9660 |
GA-9670 |
GA-9680 |
GA-9680B |
Appearance |
white |
black |
|||||
William plasticity |
160 |
180 |
200 |
220 |
240 |
270 |
270 |
Hardness(ShoreA) |
30 |
40 |
50 |
60 |
70 |
76 |
79 |
Density(g/cm³) |
2.1 |
2.13 |
2.15 |
2.2 |
2.25 |
2.04 |
2.35 |
Tensile strength(Mpa) |
1.0 |
1.5 |
2.0 |
2.0 |
2.5 |
4.5 |
4.7 |
Elongation(%) |
800 |
750 |
700 |
600 |
500 |
80 |
130 |
Tear strength(KN/m) |
6 |
6 |
6 |
10 |
10 |
8.0 |
11.3 |
Coefficient of thermal |
0.8 |
0.8 |
0.8 |
0.9 |
0.9 |
0.8 |
0.9 |
As one of the most professional silicone rubber manufacturers in china, we provide moulding silicone, coating silicone, oil silicone and etc. For more information about thermal conductivity of silicon rubber, please feel free to contact us!
