Type1 Portable EV Charging Cable
The cable conforms to the SAE Standard (USA) of EV Charging, which suits electric vehicles manufactured in America. As mostly customer had asked, it has a unique design that one button attached with a hole (reserved for the electronic lock to avoid stealing) on the top of the connector. It consists of Control Box and USA Plug at the tail end, a nice solution for charging.
Features of Jayuan Type 1 Portable EV Charging Cable
Matching SAE J1772-2012.
Ergonomic design.
Convenient connector.
Advanced craft shows a nice appearance.
Longer lifespan and better bending thanks to XLPO & TPU material.
The control box of these Type-1 electric charging cables is adjustable to 10A/13A/16A.
Special internal waterproof protection.
Specifications of Specifications of Jayuan Type 1 Portable Mobile Electric Vehicle Charging Cable
|
Electrical |
Environment |
Materials |
Mechanical |
||||
|
Insulation Resistance: |
>1000MΩ (DC500V) |
Operating Temperature: |
-30℃~50℃ |
Shell (Thermoplastic): |
UL94-VO |
Life: |
no-load plug>10000times |
|
Flame Retardent |
|||||||
|
Pins Temperature Rise: |
<50K</span> |
Waterproof IP Grade: |
IP55 |
/ |
/ |
External Force: |
1meters Drop and 2tons vehicle run over pressure affordable. |
|
Withstand Voltage: |
2500V |
/ |
/ |
/ |
/ |
Insertion Force: |
<100N</span> |
|
Contact Impedance: |
0.5mΩMax |
/ |
/ |
/ |
/ |
/ |
/ |
