VE3 Vertical Slewing Drive for Solar tower
Quantité : 1000pcs Prix : contact us
VE3 Vertical Slewing Drive for Solar tower
Brand Name: FRB
Model Number: VE3
Specification: Normal
Application: Industrial
Output Torque: 400 N.m
TiltingMomentTorque: 500 N.m
Holding Torque: 2000 N.m
Static Axial Rating: 30 kN
Tracking Precision: ≤ 0.2°
Gear Ratio : 62 : 1
Motor: 12V,24V,DC motor,280V,320V AC motor
Net Weight: 45 Kg
Delivery Time: Within 15 working days after order confirmed and payment received.
Vertical designing is the biggest bright spot of FRB slewing drives,the Vertical designing main used for the solar tracker system,the special structure simplifies the complex structure of the EPC bracket, Reducing the cost of whole system, the vertical designing is more competitive in the market.
Application:
1) VE series slewing drive widely used for relative rotation parts of the solar tracker and Machine field.
2) The Vertical rotation of single axis Solar PV, Inclined sign axis solar PV CSP, CPV Etc.
3) Welding machine.
Personne à contacter : Hedy Yang, 86 379 63287520
