VE9A slewing drive for solar tracking
Quantité : 1000pcs Prix : contact us
VE9A slewing drive for solar tracking
Brand Name: FRB
Model Number: VE9A-61-25R
Type: slewing drive for solor power
Output torque: 6.5kNm
Tilting moment torque: 12kN.m
Holding torque: 12kN.m
Static Axial rating: 12kN
Static radial rating: 338kN
Dynamic axial rating: 120kN
Dynamic radial rating: 81kN
Tracking Precision: ≤ 0.17°
Gear Ratio: 61: 1
motor: 12V,24V DC motor,220V,230V,240V,380V AC motor
Optional Items: 12V,24V DC motor,220V,230V,240V,380V AC motor motor, Encoder
Delivery Time: Within 15 working days after order confirmed and payment received.
Vertical designing is the biggest bright spot of FRB slewing drives,the Vertical designing main used for the solar tracker system,the special structure simplifies the complex structure of the EPC bracket, Reducing the cost of whole system, the vertical designing is more competitive in the market.
Application:
1) VE series slewing drive widely used for relative rotation parts of the solar tracker and. Machine field.
2) The Vertical rotation of single axis Solar PV, Inclined sign axis solar PV CSP, CPV Etc.
3) Welding machine.
