Light Cure Conformal Coating - L226
Quantité : 2000TON
Led seal spray - L226
FEATURES OF GOLOHO-L226
UV rapid cure
one-component, 100% solid content
low viscosity
emperature resistance: -55~120℃
Description
GOLOHO-L226 is a single component, UV curable, acrylated modified conformal coating
TYPICAL APPLICATIONS OF GOLOHO-L226
Coating and protection on the complex shape of PCB and integrated circuit
Model |
L226 |
Appearance |
light-yellow transparent liquid |
Resin |
acrylated modified |
Solid content % |
100 |
Density g/cm3 |
1.09 ± 0.05 |
Viscosity cP@25℃ |
200 ~ 400 |
Cure time s |
15 ± 5 |
Illumination intensity mJ/cm2 |
800~1000 |
Temperature resistance ℃ |
-55~120 |
Dielectric strength kV/mm |
43 |
Volume Resistivity Ω·cm |
6.3×1011 |
Dielectric constant 1MHz |
4.01 |
Dielectric dissipation factor 1MHz |
0.12 |
HOW TO USE GOLOHO-L226
As it is sensitive to light, these kinds of light like sunlight, UV, artificial light must be controlled to decrease its exposure during storage and handing process.
All surface in contact with the material should be clean and free from impurity, grease, or other contaminants prior to dispensing the material to acquire expectant results
Application methods: artificial brush, mechanic spray, dip
Cure: proper length wave UV light is needed to achieve constant depth of cure, and the cure time depend on the lamp intensity and distance from the source
Some temperature sensitive substrate should be cooled before coating.
SPECIAL VERSION OF GOLOHO-L226
The product is nontoxic after curing, but avoid contact with skin. If contact the compound with eyes, rinse immediately with plenty of water
SHELF LIFE AND STORAGE CONDITIONS OF GOLOHO-L226
Shelf life: in sealed original containers 12 months at 5~25℃
Storage: protect from UV light, protect against humidity
FOR USERS
Without notice, the contents of this article may be changed due to the product performance improvement and specification.
We just only ensure the specifications of our products. You have to test the product before using to conform if it is suitable for your use.
Our products are developed for general industrial use.
The data are real expression in the existing test methods and results of GOLOHO POLYMER in this paper. However, because of the uniqueness of every application, the product information can never replace necessary testing before user's applying. The user's test results are the only way to ensure the product is suitable for their specific application requirements. Therefore, unless a written guarantee, GOLOHO POLYMER only ensures the products comply with the factory specifications. GOLOHO POLYMER never recognizes any other form of guarantee and claim clause. GOLOHO POLYMER has the right to test again for product quality if there is any quality problem. GOLOHO POLYMER will provide replacement or refund if any quality problem confirm. Users should be responsible for ensuring that their applications comply with local safety regulations and obtain the necessary certifications and recognition. GOLOHO POLYMER does not undertake any responsibility for any safety and loss problems.
Please contact the company's customer service if you want to reprint the contents of the products. Customer service hotline: 0519-85610389; for more details, please visit web site: goloho@sina.com
